| Quantity: | |
|---|---|
Specification:
| Basics | Model | YABP680-025G/028P-4 |
| Capacity | 25 hp (18.5 kW) | |
| Shipping weight | 18 kg | |
| Dimension | 423*258*230 mm | |
| I/O Feature | Rated current | 37A at 380V ~ 480V, 75A at 220V ~ 240V |
| Input voltage | 3 phase 240V /420V /480V AC ±15% (Optional) | |
| Input frequency | 50Hz/ 60Hz | |
| Output voltage | 3 phase AC 0~input voltage | |
| Output frequency | 0.00~400.00Hz | |
| Over load capacity | 150% of rated current for 1 minute, 180% of rated current for 3 seconds | |
| Control Feature | Control mode | V/F control; Sensorless vector control; |
| Communication | RS485 | |
| Speed regulation | 1:100 | |
| Start torque | 150% of rating torque at 1 Hz | |
| Speed control accuracy | ≤±0.5% of rating synchronous speed | |
| Frequency precision | Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2% | |
| Frequency resolution | Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz | |
| Torque boost | Automatic torque boost, manual torque boost 0.1%~30.0% | |
| Interior PID controller | Be convenient to make closed-loop system | |
| Automatic energy save running | Optimize V/F curve automatically based on the load to realize power save running | |
| Automatic voltage regulation (AVR) | Can keep constant output voltage when power source voltage varies. | |
| Automatic current limiting | Limit running current automatically to avoid frequent over-current which will cause trip | |
| Environment | Enclosure rating | IP 20 |
| Temperature | –10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5% | |
| Humidity | 5%-95%, without condensation | |
| Altitude | ≤1000m; VFD will be derated if above 1000m | |
| Impingement and oscillation | Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g) | |
| Store environment | –20℃~ +60℃; no dust, no corrosive gas, no direct sunlight |
High Voltage Capacity: The High Voltage Electric Frequency Converter is designed to handle high voltage inputs, ensuring seamless integration into industrial systems that require stable power supply.
Precise Frequency Control: It provides accurate frequency adjustments, optimizing the performance of connected equipment.
Reliable Performance: Built with robust technology, this frequency converter guarantees consistent operation under demanding conditions.
Enhanced Protection Features: The device includes built-in safety mechanisms such as overload, short circuit, and over-temperature protection to prevent system failures.
Efficient Energy Use: By optimizing frequency control, it helps reduce energy consumption and enhances system efficiency.
Stability and Reliability: The High Voltage Electric Frequency Converter ensures a stable power output, crucial for sensitive industrial machinery and systems.
Improved System Lifespan: By providing smooth and controlled power, it minimizes wear and tear on equipment, extending the lifespan of motors and other components.
Reduced Power Loss: The efficient frequency conversion minimizes power losses, offering cost savings in the long run.
Wide Range of Applications: This converter is ideal for industries that use high-voltage electrical systems, such as manufacturing, energy generation, and heavy machinery.
Advanced Protection Features: The built-in protection mechanisms ensure the safety of connected devices, preventing potential damage from power surges and faults.
Industrial Equipment: Ideal for controlling motors and other high-power machinery in factories and plants.
Energy Generation: Suitable for power plants that require high-voltage frequency control.
Heavy Machinery: Ensures smooth operation in construction, mining, and other heavy-duty sectors.
HVAC Systems: Can be used in large HVAC systems that need high-voltage frequency control for efficient operation.
Electronics Manufacturing: Used in production lines where precise frequency control is essential for machinery.
Q1: What is the purpose of the High Voltage Electric Frequency Converter?
A1: The primary purpose of the High Voltage Electric Frequency Converter is to convert high-voltage electrical frequencies to ensure stable and efficient power for industrial equipment.
Q2: Can this frequency converter be used for any voltage level?
A2: The High Voltage Electric Frequency Converter is specifically designed for high-voltage environments and can handle a wide range of high voltage inputs.
Q3: How does the frequency converter help improve system efficiency?
A3: By providing precise frequency control, the High Voltage Electric Frequency Converter reduces power losses and optimizes the performance of connected equipment.
Q4: Is the device easy to integrate into existing systems?
A4: Yes, the High Voltage Electric Frequency Converter is designed for easy integration into existing industrial systems and machines that require stable power supply.
Q5: Does the converter offer protection against electrical faults?
A5: Yes, the High Voltage Electric Frequency Converter is equipped with overload, short circuit, and over-temperature protection to ensure safe operation and prevent damage.
